Aluminium Window Door Profile Roller
By: Shandong Apex CNC Machinery Co., Ltd.
CategoryExtrusion StretcherManufacturerShandong Apex CNC Machinery Co., Ltd.Min Order Quantity1.00 UnitDelivery Lead TimeAs per orderPlace of OriginChinaSupply AbilityCustomization as requiredPackaging DetailsStandard export packingTransportation DetailsRoad / Ship
*Login Required
Details
Price:Available on request
Description
Product Parameters:
| Power supply | 380V/50 Hz |
| Input power | 5.2 kW |
| Working pressure | 0.2 MPa |
| Min diameter of bending | 60MM |
| Max width of profile | 150*180 MM |
| Max diameter of rolls | 200MM |
| Lower shaft center-dimensions | 350~750 mm |
| Hydraulic cylinder pressure | 20T/25T |
| Rolls-holding shaft diameter | 60/65MM |
| Rotation speed of shaft | 1~8R/MIN |
| Positioning precision | ±0.01MM |
| Top roll runout | 200/280MM |
| Torque | 2500 N.M. |
| Overall dimension | 1300*1100*1100M |
| Machine weight | 1000 kg |
