Aluminium Hinged System
By: Group Metal
CategoryDoors and Windows AccessoriesManufacturerGroup Metal Min Order Quantity10.00 UnitDelivery Lead TimeAs per order Place of OriginEgyptSupply AbilityCustomization on requirementPackaging DetailsStandard export packingTransportation DetailsRoad / Ship
*Login Required
Details
Price:Available on request
Description
| Profile Technical Specification | |
| Extruded Alloy | AlMgSi (EN AW 6063) |
| Hardness | 12 Webster or 70 HB minimum |
| Minimum Powder Coating Thickness | 75μm minimum |
| Profile Thickness (min-max) | 1,1 – 1,4 mm |
| Profile Geometry Control | EN DIN 12020-2 Compliant |
| Product Line Technical Characteristics | |
| Width for basic frame / sash | 37 / 44 mm |
| Glazing Type | Single or Double, from 10 to 26 mm |
| Glazing Weight | Up to 130 Kg per sash |
| Sealing | “ALUSEAL” perimetrical sealing system, |
| with three levels of EPDM gaskets | |
Basic characteristics:
√ 37 mm sash width
√ “ALUSEAL” perimetrical sealing system,
with three levels of EPDM gaskets
√ Supports all “tilt-and-turn” typologies
√ Cooperates perfectly with the M900 Aero for sliding frames
√ Supports single or double glazing, from 10 to 26 mm
